| Blade Tip Angle – Front | 40 ° |
| Blade Tip Angle – Rear | 5 ° |
| Diameter | 60.2 in (152 cm) |
| Max Lift Above Ground | 18.9 in (46 cm) |
| Max Reach Outside Tires – Left | 74.6 in (188 cm) |
| Max Reach Outside Tires – Right | 77.9 in (196 cm) |
| Shift Left | 27.4 in (69 cm) |
| Shift Right | 28.7 in (71 cm) |
Dimensions
| Blade Base | 8.4 ft (2 m) |
| Front Ground Clearance | 2 ft (1 m) |
| Height to Top of Isomount Cab | 10.3 ft (3 m) |
| Overall Length | 28.6 ft (9 m) |
| Rear Ground Clearance | 1.2 ft (0 m) |
| Tandem Axle Wheelbase | 5 ft (2 m) |
| Wheelbase | 20.3 ft (6 m) |
| Width Over Tires | 8.1 ft (2 m) |
Engine
| Displacement | 629 cu in (0 m) |
| Engine Model | 3176C DITA ATAAC VHP |
| Max Power | 185 hp (138 kw) |
| Net Power Gear 1-2 | 165 hp (123 kw) |
| Net Power Gear 4-6 | 185 hp (138 kw) |
| Net Power Gear 5-6 | 185 hp (138 kw) |
| Net Power Gears 7-8 | 185 hp (138 kw) |
| Number of Cylinders | 6 |
| Power Measured @ | 2000 rpm |
Front Axle
| Ground Clearance | 2 ft (1 m) |
| Oscillation – Total | 32 ° |
| Wheel Lean | 18 ° |
