| Engine Power @ 1,600 rpm – ISO 14396:2002 | 321 HP |
| Gross Power @ 1,600 rpm – SAE J1995:2014 | 325 HP |
| Engine Model | Cat C9.3B |
| Net Power @ 1,600 rpm – ISO 9249:2007, SAE J1349:2011 | 303 HP |
| Note (1) | Cat engine meets U.S. EPA Tier 4 Final, EU Stage V, Korea Stage V, China Nonroad Stage IV and Japan 2014 emission standards. |
| Note (2) | The net power advertised is the power available at the flywheel when the engine is equipped with fan, alternator, air cleaner, and aftertreatment. |
| Net Torque @ 1,200 rpm – ISO 9249:2007, SAE J1349:2011 | 1255 ft-lb |
| Engine Torque @ 1,200 rpm – ISO 14396:2002 | 1313 lb/ft |
| Gross Torque @ 1,200 rpm – SAE J1995:2014 | 1327 lb/ft |
| Note (3) | Cat diesel engines are required to use ULSD (ultra-low sulfur diesel fuel with 15 ppm of sulfur or less) or ULSD blended with the following lower-carbon intensity fuels up to: • 20% biodiesel FAME (fatty acid methyl ester)* • 100% renewable diesel, HVO (hydrogenated vegetable oil) and GTL (gas-to- liquid) fuels Refer to guidelines for successful application. Please consult your Cat dealer or “Caterpillar Machine Fluids Recommendations” (SEBU6250) for details. * Engines with no aftertreatment devices can use higher blends, up to 100% biodiesel. |
| Displacement | 9.3 L |
WEIGHTS
| Operating Weight | 51124 lb |
| Note | Weight based on a machine configuration with Bridgestone 29.5R25 VSNT L4 radial tires, full fluids, operator, standard counterweight, ride control cold start, roading fenders, Product Link, open differential axles (front/rear), secondary steering, sound suppression, and a 5.4 m³ (7.1 yd³) general purpose bucket with BOCE. |
